I notebook stanno diventando sempre più veri centri di intrattenimento e per divertirsi con film, foto, giochi, musica e media digitali. Sempre attenta alle esigenze e alle richieste degli utenti, Acer apre una nuova era di esperienza dell’utente portando sul mercato un’intera gamma di notebook progettati per offrire intrattenimento e visualizzazione ad alta definizione e a immersione totale oltre a una straordinaria performance.
Unendo l’ultima generazione della tecnologia VISION dotata dei processori AMD, che introducono la performance multi-core nel mondo dei notebook, alle straordinarie grafiche ATI Radeon™ e alle tecnologie ad alta definizione, la nuova serie di notebook Aspire è progettata per offrire una visione superiore e il meglio in termini di intrattenimento. Infatti, questi notebook sono appositamente progettati per garantire la performance multitasking desiderata dall’utente per sfruttare al massimo il mondo dell’alta definizione: film, foto, giochi 3D, musica e TV.
I nuovi notebook Aspire sono dotati di tutto ciò che serve all’utente per godere di un’esperienza di intrattenimento straordinaria; offrono inoltre eccezionali performance per la produttività o per divertirsi a casa o in movimento. In un design elegante con profili lineari, tutte le ultime tecnologie offrono una funzionalità superiore, audio e video eccezionali e connettività affidabile.
Il fiore all’occhiello della serie è Aspire 7552G che unisce look e potenza per offrire un’esperienza completamente nuova all’utente. Grazie alla tecnologia VISION – Black di AMD, questo notebook diventa una vera centrale di energia: i nuovi processori AMD Phenom II Quad-Core Mobile garantiscono performance ultra rapide e in multitasking; inoltre consentono di visualizzare in modo ottimale i video HD con le migliori grafiche ATI Mobility Radeon™ HD. Il risultato è una performance pari a quella di un desktop e un incredibile intrattenimento in HD, con qualità visiva senza paragoni in un notebook che offre un’autonomia della batteria prolungata. Multitasking avanzato, giochi mozzafiato in 3D, editing di musica e foto, creazione/editing di filmati HD: Aspire 7552G è lo strumento perfetto per permettervi di liberare la vostra creatività ovunque vi troviate.
Niente è impossibile per questo notebook da 17,3”. Che siate interessati a giochi, musica, foto o video, Aspire 7552G vi consentirà di divertirvi con giochi incredibilmente reali, riprodurre contenuti HD, convertire semplicemente musica e video HD per i lettori multimediali portatili, registrare e modificare musica o video, creare/modificare filmati HD, eseguire editing avanzato delle foto, senza perdere neanche un attimo. Liberate la vostra immaginazione, perché Aspire 7552G è in grado di fare tutto ciò che potete immaginare.
La vita digitale diventa realtà con Aspire 7552G. Il formato 16:9 nativo e il display Acer CineCrystal™ retroilluminato a LED con risoluzione HD+ offrono una reale visione cinematografica, con immagini realistiche, intensa saturazione del colore e contrasto superiore, rendendo la visione di film o di giochi un vero piacere. Inoltre, un’unità Blu-ray Disc™ è dotata della migliore qualità audio-video di alta definizione per la visione di film straordinari. La ciliegina sulla torta è la porta HDMI™ per collegarsi a TV e proiettori in full HD per un fantastico intrattenimento cinematografico.
La gamma comprende inoltre la serie di notebook Aspire x551 disponibile nei formati 14,1”, 15,6” e 17,3” tutti caratterizzati da ottime performance grafiche ad alta definizione per offrire agli utenti una straordinaria esperienza durante la visione, la creazione o la condivisione di contenuti digitali HD. Con un’offerta così ricca, sicuramente tutti troveranno la soluzione perfetta per le proprie esigenze.
***
Detailed information on Acer products and a catalogue with prices in PDF format are available on Acer’s website www.acer.com
Il gruppo Acer
Sin dalla fondazione nel 1976, Acer ha perseguito l’obiettivo di abbattere le barriere tra le persone e la tecnologia. A livello internazionale, Acer è seconda nel mercato globale dei PC. Un modello di canale proficuo e sostenibile è basilare per la continua crescita della società, mentre il suo approccio multi-brand integra efficacemente i marchi Acer, Gateway, Packard Bell ed eMachines nei mercati internazionali. Acer si impegna a progettare prodotti ecologici e a creare una supply chain “verde” tramite la collaborazione con i fornitori. Acer è fiera di essere un Worldwide Partner del Movimento Olimpico, delle Olimpiadi invernali di Vancouver 2010 e dei Giochi Olimpici di Londra del 2012. Il Gruppo Acer impiega 7.000 persone in tutto il mondo con un fatturato stimato per il 2009 di 17,9 miliardi di US$.
Per ulteriori informazioni, vedere www.acer-group.com.
© 2010 Acer Inc. All rights reserved. Acer and the Acer logo are registered trademarks of Acer Incorporated. Microsoft and Windows are registered trademarks of Microsoft Corporation. Intel and Pentium are registered trademarks of Intel Corporation. Other trademarks, registered trademarks and/or service marks, indicated or otherwise, are the properties of their respective owners.
Aspire 7552G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II Black Edition quad-core mobile processor X920 (2 MB L2 cache, 2.30 GHz, 1333 MHz FSB, 45 W)
AMD Phenom™ II Black Edition dual-core mobile processor X620 (2 MB L2 cache, 3.10 GHz, 1333 MHz FSB, 45 W)
AMD Phenom™ II quad-core mobile processor N930 (2 MB L2 cache, 2 GHz, 1333 MHz FSB, 35 W), P920 (2 MB L2 cache, 1.60 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, 1333 MHz FSB, 35 W), P820 (1.5 MB L2 cache, 1.80 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II dual-core mobile processor N620 (2 MB L2 cache, 2.80 GHz, 1333 MHz FSB, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, 1066 MHz FSB, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, 1066 MHz FSB, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradeable to 12 GB using three soDIMM modules5 (for 64-bit OS)
• Up to 4 GB of DDR3 1066 MHz memory, upgradeable to 8 GB using three soDIMM modules5 (for 64-bit Windows® 7 Home Basic only)
Display 17.3″ HD 1600 x 900 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ LED-backlit TFT LCD
Mercury free, environment friendly
16:9 aspect ratio
8 ms response time
60% color gamut
Graphics1 ATI Mobility Radeon™ HD 5850 with 1024MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL ® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5650 with 1024 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with 512 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL ® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rate6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
Microsoft® DirectX Video Acceleration (DXVA) application interface (API)
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage One or two 160/250/320/500/640 GB or larger hard disk drives1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™ writer/DVD-SuperMulti double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 4X BD-RE, 4X BD-ROM DL, 4X BD-R DL
• Write: 24X CD-R, 10X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL, 4X BD-R, 2X BD-RE, 4X BD-R DL
4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 415 (W) x 275 (D) x 27.1/34.3 (H) mm (16.3 x 10.8 x 1.07/1.35 inches)
3.3 kg (7.26 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (.86 lbs.)10 with 180 cm DC cable
3-pin 120 W AC adapter:
• 155 (W) x 67 (D) x 36.5 (H) mm (6.1 x 2.63 x 1.43 inches)
• 570 g (1.25 lbs.)10 with 180 cm DC cable
Acer QuicCharge™ technology11:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
Standard:
• 48.8 W 4400 mAh 6-cell Li-ion battery pack
High-capacity:
• 99 W 9000 mAh 9-cell Li-ion battery pack
Estimated battery life: 2.2 hours12 with standard battery pack; 4.5 hours12 with high-capacity battery pack
ENERGY STAR®
Product Safety Electric Appliance and Materials (PSE) certified for battery pack
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout, 1.8 mm (minimum) key travel
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
11 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Four USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Microsoft® Office Personal 2007 (Service Pack 2)1
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial13
• MyWinLocker®1
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone1
• WildTangent®1
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Web links and utilities
• Acer Accessory Store1
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
9-cell Li-ion battery pack
3-pin 90 W AC adapter
3-pin 120 W AC adaptor
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
1. Specifications vary depending on model.
2. 64-bit software is required to enjoy the advantages of 64-bit processing.
3. Up to 1 GB of available system memory may be allocated for system resource requirements.
4. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
5. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
6. Resolution/refresh rates depend on display capability and color/depth settings.
7. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
8. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
9. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
10. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
11. Supported on 4400, 4800 and 5200 mAh battery packs only.
12. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
13. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved. Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 7551G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II quad-core mobile processor N930 (2 MB L2 cache, 2 GHz, 1333 MHz FSB, 35 W), P920 (2 MB L2 cache, 1.60 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, 1333 MHz FSB, 35 W), P820 (1.5 MB L2 cache, 1.80 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II dual-core mobile processor N620 (2 MB L2 cache, 2.80 GHz, 1333 MHz FSB, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, 1066 MHz FSB, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, 1066 MHz FSB, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5 (for 64-bit OS)
Display 17.3″ HD+ 1600 x 900 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ LED-backlit TFT LCD
Mercury free, environment friendly
16:9 aspect ratio
8 ms response time
60% color gamut
Graphics1 ATI Mobility Radeon™ HD 5650 with 1024 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with 512 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL ® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rate6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
Microsoft® DirectX Video Acceleration (DXVA) application interface (API)
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 415 (W) x 275 (D) x 27.1/34.3 (H) mm (16.3 x 10.8 x 1.07/1.35 inches)
3.3 kg (7.26 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (.86 lbs.)10 with 180 cm DC cable
Acer QuicCharge™ technology11:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 2.7 hours12
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout, 1.8 mm (minimum) key travel
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
11 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Microsoft® Office Personal 2007 (Service Pack 2)1
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial13
• MyWinLocker®1
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone1
• WildTangent®1
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Web links and utilities
• Acer Accessory Store1
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 90 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
14. Specifications vary depending on model.
15. 64-bit software is required to enjoy the advantages of 64-bit processing.
16. Up to 1 GB of available system memory may be allocated for system resource requirements.
17. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
18. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
19. Resolution/refresh rates depend on display capability and color/depth settings.
20. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
21. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
22. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
23. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
24. Supported on 4400, 4800 and 5200 mAh battery packs only.
25. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
26. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 7551 Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II quad-core mobile processor N930 (2 MB L2 cache, 2 GHz, 1333 MHz FSB, 35 W), P920 (2 MB L2 cache, 1.60 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, 1333 MHz FSB, 35 W), P820 (1.5 MB L2 cache, 1.80 GHz, 1066 MHz FSB, 25 W)
AMD Phenom™ II dual-core mobile processor N620 (2 MB L2 cache, 2.80 GHz, 1333 MHz FSB, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, 1066 MHz FSB, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, 1066 MHz FSB, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5 (for 64-bit OS)
Display 17.3″ HD+ 1600 x 900 pixel resolution, high-brightness (220-nit) Acer CineCrystal™ LED-backlit TFT LCD
Mercury free, environment friendly
16:9 aspect ratio
8 ms response time
60% color gamut
Graphics1 ATI Radeon™ HD 4250 with 256 MB of dedicated system memory, supporting Unified Video Decoder 2 (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
Dual independent display support
16.7 million colors
External resolution / refresh rate6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 415 (W) x 275 (D) x 27.1/34.3 (H) mm (16.3 x 10.8 x 1.07/1.35 inches)
3.3 kg (7.26 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (.49 lbs.)10 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 3 hours12
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout, 1.8 mm (minimum) key travel
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
11 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Microsoft® Office Personal 2007 (Service Pack 2)1
• Microsoft® Office Trial (Service Pack 2)
• Microsoft® Works
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial13
• MyWinLocker®1
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone1
• WildTangent®1
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Web links and utilities
• Acer Accessory Store1
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 soDIMM module
6-cell Li-ion battery pack
3-pin 65W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
27. Specifications vary depending on model.
28. 64-bit software is required to enjoy the advantages of 64-bit processing.
29. Up to 1 GB of available system memory may be allocated for system resource requirements.
30. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
31. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
32. Resolution/refresh rates depend on display capability and color/depth settings.
33. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
34. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
35. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
36. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
37. Supported on 4400, 4800 and 5200 mAh battery packs only.
38. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
39. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 5551G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, 1333 MHz FSB, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, 1066 MHz FSB, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, 1066 MHz FSB, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using two soDIMM modules5 (for 64-bit OS)
Display 15.6″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD
16:9 aspect ratio
Graphics1 ATI Mobility Radeon™ HD 5650 with 1024 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with 512 MB of dedicated DDR3 VRAM, supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL ® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rate6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
Microsoft® DirectX Video Acceleration (DXVA) application interface (API)
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 381 (W) x 253 (D) x 25/34 (H) mm (15 x 9.9 x .98/1.3 inches)
2.6 kg (5.74 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (.86 lbs.)10 with 180 cm DC cable
Acer QuicCharge™ technology11:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 2 hours and 40 minutes12
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout, 1.8 mm (minimum) key travel
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
11 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial1 (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial16
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 90 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
40. Specifications vary depending on model.
41. 64-bit software is required to enjoy the advantages of 64-bit processing.
42. Up to 1 GB of available system memory may be allocated for system resource requirements.
43. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
44. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
45. Resolution/refresh rates depend on display capability and color/depth settings.
46. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
47. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
48. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
49. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
50. Supported on 4400, 4800 and 5200 mAh battery packs only.
51. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
52. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 5551 Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, 1333 MHz FSB, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, 1066 MHz FSB, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, 1066 MHz FSB, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 1066 MHz memory, upgradable to 8 GB using three soDIMM modules5 (for 64-bit OS)
Display 15.6″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD
16:9 aspect ratio
Graphics ATI Radeon™ HD 4250 Graphics with 256 MB of dedicated system memory, supporting Unified Video Decoder 2 (UVD2), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2456 x 1536: 60 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive1 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 381 (W) x 253 (D) x 25/34 (H) mm (15 x 9.9 x 0.98/1.3 inches)
2.6 kg (5.74 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (.49 lbs.)10 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 3 hours and 20 minutes11
ENERGY STAR®
Special keys and controls 103-/104-/107-key keyboard, with inverted “T” cursor layout, 1.8 mm (minimum) key travel
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
11 function keys, four cursor keys, two Windows® keys, hotkey controls, independent standard numeric keypad, international language support
Media keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google™ Setup
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial1 (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite 2009 Trial16
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Microsoft® Silverlight™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Assist
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 1066 MHz soDIMM module
6-cell Li-ion battery pack
3-pin 65 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
53. Specifications vary depending on model.
54. 64-bit software is required to enjoy the advantages of 64-bit processing.
55. Up to 1 GB of available system memory may be allocated for system resource requirements.
56. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
57. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
58. Resolution/refresh rates depend on display capability and color/depth settings.
59. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
60. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
61. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
62. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
63. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
64. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 4551G Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II quad-core mobile processor N930 (2 MB L2 cache, 2 GHz, DDR3 1333 MHz, 35 W)
AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz, DDR3 1333 MHz, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, DDR3 1066 MHz, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, DDR3 1066 MHz, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5 (for 64-bit OS)
Display 14.0″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing
16:9 aspect ratio
Graphics1 ATI Mobility Radeon™ HD 5650 with up to 4091 MB of HyperMemory™ (1024 MB of dedicated DDR3 VRAM, up to 3067 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
ATI Mobility Radeon™ HD 5470 with up to 3579 MB of HyperMemory™ (512 MB of dedicated DDR3 VRAM, up to 3067 MB of shared system memory), supporting Unified Video Decoder (UVD), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 5.0, Microsoft® DirectX® 11, OpenGL® 3.1, OpenCL™ 1.1
Dual independent display support
16.7 million colors
External resolution / refresh rate6:
• VGA port up to 2048 x 1536: 85 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
VC-1 and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 342 (W) x 245 (D) x 25.5/31.9 (H) mm (13.5 x 9.6 x 1.00/1.26 inches)
2.2 kg (4.85 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
3-pin 90 W AC adapter:
• 133 (W) x 59 (D) x 31 (H) mm (5.23 x 2.32 x 1.22 inches)
• 390 g (.86 lbs.)10 with 180 cm DC cable
Acer QuicCharge™ technology11:
• 80% charge in 1 hour
• 2-hour rapid charge system-off
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 3 hours12
ENERGY STAR®
Special keys and controls 86-/87-/91-key keyboard, with inverted “T” cursor layout
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, embedded numeric keypad, international language support
Media control keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial1 (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial12
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 soDIMM module
6-cell Li-ion battery pack
3-pin 90 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
65. Specifications vary depending on model.
66. 64-bit software is required to enjoy the advantages of 64-bit processing.
67. Up to 1 GB of available system memory may be allocated for system resource requirements.
68. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
69. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
70. Resolution/refresh rates depend on display capability and color/depth settings.
71. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
72. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
73. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
74. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
75. Supported on 4400, 4800 and 5200 mAh battery packs only.
76. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
77. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Aspire 4551 Specifications
Operating system1 Genuine Windows® 7 Home Premium 64-bit2
Genuine Windows® 7 Home Basic 64-bit2
CPU/chipset1 AMD Phenom™ II quad-core mobile processor N930 (2 MB L2 cache, 2 GHz, DDR3 1333 MHz, 35 W)
AMD Phenom™ II triple-core mobile processor N830 (1.5 MB L2 cache, 2.10 GHz,DDR3 1333 MHz, 35 W)
AMD Turion™ II dual-core mobile processor P520/N530 (2 MB L2 cache, 2.30/2.50 GHz, DDR3 1066 MHz, 25/35 W)
AMD Athlon™ II dual-core processor P320/N330 (1 MB L2 cache, 2.10/2.30 GHz, DDR3 1066 MHz, 25/35 W)
AMD M880G Chipset
System memory1, 3, 4 Dual-channel DDR3 SDRAM support:
• Up to 4 GB of DDR3 system memory, upgradable to 8 GB using two soDIMM modules5 (for 64-bit OS)
Display 14.0″ HD 1366 x 768 pixel resolution, high-brightness (200-nit) Acer CineCrystal™ LED-backlit TFT LCD, supporting simultaneous multi-window viewing
16:9 aspect ratio
Graphics ATI Radeon™ HD 4250 Graphics with 256 MB of dedicated system memory, supporting Unified Video Decoder 2 (UVD2), OpenEXR High Dynamic-Range (HDR) technology, Shader Model 4.0, Microsoft® DirectX® 10.1
Dual independent display support
16.7 million colors
External resolution / refresh rates6:
• VGA port up to 2456 x 1536: 60 Hz
• HDMI™ port up to 1920 x 1080: 60 Hz
MPEG-2/DVD decoding
WMV9 (VC-1) and H.264 (AVC) decoding
HDMI™ (High-Definition Multimedia Interface) with HDCP (High-bandwidth Digital Content Protection) support
Audio Two built-in Acer 3DSonic™ stereo speakers
High-definition audio support
Built-in microphone
MS-Sound compatible
Storage 160/250/320/500/640 GB or larger hard disk drive1, 7
Multi-in-1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard (MMC), Memory Stick™ (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
Optical media drive1 4X Blu-ray Disc™/DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 8X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 8X DVD-RW, 8X DVD+RW, 5X DVD-RAM, 4X BD-ROM, 4X BD-R, 2X BD-RE, 4X BD-ROM DL, 4X BD-R DL, 2X BD-RE DL
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM, 4X DVD+R DL, 4X DVD-R DL
8X DVD-Super Multi double-layer drive:
• Read: 24X CD-ROM, 24X CD-R, 24X CD-RW, 8X DVD-ROM, 8X DVD-R, 8X DVD+R, 6X DVD-ROM DL, 6X DVD-R DL, 6X DVD+R DL, 6X DVD-RW, 6X DVD+RW, 5X DVD-RAM
• Write: 24X CD-R, 16X CD-RW, 8X DVD-R, 8X DVD+R, 4X DVD-R DL, 4X DVD+R DL, 6X DVD-RW, 8X DVD+RW, 5X DVD-RAM
Communication Acer Video Conference1, featuring:
• Acer Crystal Eye 1.3 MP webcam, 1280 x 1024 resolution
WLAN1, 8, 9:
• Acer InviLink™ Nplify™ 802.11b/g/n Wi-Fi CERTIFIED™
• Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED™
• Supporting Acer SignalUp™ wireless technology
WPAN1:
• Bluetooth® 3.0+HS
• Bluetooth® 2.1+EDR
LAN: Gigabit Ethernet, Wake-on-LAN ready
Privacy control1 BIOS user, supervisor, HDD passwords
Kensington lock slot
Dimensions and weight 342 (W) x 245 (D) x 25.5/31.9 (H) mm (13.5 x 9.6 x 1.00/1.26 inches)
2.2 kg (4.85 lbs.)10 with 6-cell battery pack
Power adapter and battery ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
Acer PowerSmart 3-pin 65 W AC adapter:
• 108 (W) x 46 (D) x 29.5 (H) mm (4.25 x 1.81 x 1.16 inches)
• 225 g (.49 lbs.)10 with 180 cm DC cable
48.8 W 4400 mAh 6-cell Li-ion standard battery pack
Estimated battery life: up to 3.5 hours11
ENERGY STAR®
Special keys and controls 86-/87-/91-key keyboard, with inverted “T” cursor layout
Multi-gesture touchpad, supporting two-finger scroll, pinch, rotate, flip
10 function keys, four cursor keys, two Windows® keys, hotkey controls, embedded numeric keypad, international language support
Media control keys (printed on keyboard): play/pause, stop, previous, next
I/O ports Multi-in-1 card reader (SD™, MMC, MS, MS PRO, xD)
Three USB 2.0 ports
HDMI™ port with HDCP support
External display (VGA) port
Headphone/speaker/line-out jack
Microphone-in jack
Ethernet (RJ-45) port
DC-in jack for AC adapter
Software Productivity
• Acer Backup Manager1
• Acer ePower Management1
• Acer eRecovery Management
• Adobe® Flash® Player 10
• Adobe® Reader® 9.1
• eSobi™
• Google Toolbar™
• Microsoft® Office Personal 2007 (Service Pack 2)1 (Japan only, subject to customer request)
• Microsoft® Office Trial1 (Service Pack 2)
• Microsoft® Works SE 91 (Brazil, Canada, France, Germany, Poland, Russia, UK and US only)
• Microsoft® Works 91
• Microsoft® Works 8.51
• Norton™ Online Backup
Security
• McAfee® Internet Security Suite Trial12
• McAfee® Virus Definitions
• MyWinLocker®1 (except China, Hong Kong)
Multimedia
• Cyberlink® PowerDVD™
• NTI Media Maker™
Gaming
• Oberon GameZone Acer Edition1 (except US, Canada, Hong Kong, Korea)
• WildTangent® Acer Edition1 (US, Canada only)
Communication and ISP
• Acer Crystal Eye
• Microsoft® Silverlight™
• Skype™
• Windows Live™ Essentials — Wave 3.2 (Mail, Photo Gallery, Live™ Messenger, Movie Maker, Writer)
Utilities and tools
• Acer Accessory Store1 (Belgium, France, Germany, Italy, Netherlands, Spain, Sweden, UK only)
• Acer Identity Card
• Acer Registration
• Acer Updater
• eBay® shortcut 20091 (Canada, France, Germany, Italy, Mexico, Spain, UK, US only)
• Netflix shortcut1 (US only)
Optional items 1 GB / 2 GB / 4 GB DDR3 soDIMM module
6-cell Li-ion battery pack
3-pin 65 W AC adapter
External USB 56K modem
Warranty One-year International Travelers Warranty (ITW)
Windows®. Life without Walls™. Acer recommends Windows 7.
78. Specifications vary depending on model.
79. 64-bit software is required to enjoy the advantages of 64-bit processing.
80. Up to 1 GB of available system memory may be allocated for system resource requirements.
81. Shared system memory may be allocated to support integrated graphics, depending on system memory size and other factors. Actual system memory available to the operating system will be reduced by the amount of dedicated and shared system memory utilized by the graphics solution and resources required by the operating environment.
82. A 64-bit operating system is required to enjoy the ultimate performance of 4 GB or higher memory.
83. Resolution/refresh rates depend on display capability and color/depth settings.
84. 1 GB is 1 billion bytes. Actual formatted capacity is less and may vary depending on preloaded materials and operating environment. Acer eRecovery Management utilizes up to 10 GB of the stated hard disk capacity as dedicated backup space.
85. Actual throughput may vary depending on network conditions and environmental factors such as network traffic or overhead, building construction, and access point settings.
86. Acer Nplify™, a high-throughput wireless solution, delivers superior performance and reliable connections while enabling emerging voice, video and data applications. Wi-Fi CERTIFIED™, it supports Acer SignalUp™ wireless technology and is compliant with 802.11 a/b/g/n and 802.11 b/g standards.
87. Weight may vary depending on product configuration, vendor components, manufacturing variability, and selected options.
88. Your computer’s battery life may vary depending on product specifications, computer settings, and applications or features launched. The listed battery life is for individual battery packs tested with MobileMark 2007 in productivity test mode, and with wireless connection on. All batteries’ maximum capacity will diminish with time and use.
89. Trial periods vary depending on the geographic region and specifications: 365-day trial for China, Taiwan, Hong Kong and Singapore (Simplified Chinese and Traditional Chinese OS models); 60-day trial for other regions.
In a continuing effort to improve the quality of our products, information in this document is subject to change without notice. Images shown are only representations of some of the configurations available for this model. Availability may vary depending on region.
© 2010. All rights reserved.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
